Year of manufacture 2024
Working dimension X 5.000 mm
Working dimension Y 1.550 mm
Working dimension Z 150 mm
Number of milling spindles 1
Main motor power 12 kW
Rotation speed max 24.000 rpm
Torque support
4th axis Yes
5th axis 5-axes spindle
Milling spindle liquid-cooled
Tool clamping system HSK-F63
Tool changer positions 31
Pickup tool changer
Disc tool changer 18-fold
Vertical drilling spindles 12
Horizontal drilling spindles in X 4
Horizontal drilling spindles in Y 2
Groove saw in X-direction
Gantry machine beidseitig angetriebene Gantrymaschine
Machine table Pod and rail table
Workpiece support aids
Three stop ranges
Number of consoles 8
Pneumatic pipe connectors an den Konsolen
Vacuum pump
Number of vacuum pumps 2
Capacity vacuum pump 180 m³/h
Safety device Bumper
Interface for .dxf data
Automatic central lubrication
Tool charge measurement
Control FORMAT 4 F4 INTEGRATE
FORMAT 4 F4 INTEGRATE
Software FORMAT 4 F4, TPA ALBATROS
Declaration of CE-conformity
Conformity marking UKCA-Zeichen, CE mark
Total connection 21 kW
Weight 4.435 kg
Space requirement Length 8,9 m
Space requirement Width 3,9 m
Space requirement Height 2,65 m
