Year of manufacture 2017
Working dimension X 3.765 mm
Working dimension Y 1.560 mm
Number of milling spindles 1
Main motor power 13,2 kW
Torque support
4th axis C-axis
Tool clamping system HSK-F63
Tool changer positions 12
Disc tool changer
Vertical drilling spindles 10
BIESSE Drilling aggregate BH 10
Horizontal drilling spindles in X 4
Horizontal drilling spindles in Y 2
Groove saw in X-direction
Gantry machine Yes
Machine table Matrix table
Vacuum pump
Number of vacuum pumps 2
Capacity vacuum pump 500 m³/h
Outfeed discharge unit
BIESSE Sweeping Arm
Interface for .dxf data
Automatic lubrication
Tool charge measurement
Blow-off device
Control BIESSE BH 660
Conformity marking CE mark
Weight 3.000 kg
Unless expressly stated, tools, tool holders, aggregates, and mechanical clamps, which may be shown in photos and videos, are not part of the scope of delivery.
Technical data are partly taken from the manufacturer's brochure. Actual values may differ.
