Blade diameter 800 mm
Motor power 20 HP
5 axes controlled by the programmer: worktable rotation (0-340°) - table rotation speed 9 seconds every 180° - blade tilt from 90° to 45° (blade tilt speed 20 sec.) - blade rises above the table (speed 15 sec. every 10 cm) - beam movement and measurement (speed 17 m/min) - motorized movement of the cutting unit relative to the rear guide 600 mm
Photocell for automatic reading of the start of the piece
Cutting capacity at 90° with single cut: 280 x 290 / 250 x 390 / 200 x 450 mm
At 90° with combined cut: 280 x 770 / 250 x 840 mm
At 45° with single cut: 200 x 210 mm
At 45° with combined cut: 200 x 760 mm
Maximum trimming height: 300 mm
Cutting accuracy: +/- 2 mm on a 10 m beam (straight beam) - +/- 0.2° of table rotation angle - +/- 0.2° of blade tilt angle
Industrial PC control - Touch-screen - Windows operating system - USB ports - Ethernet
Widia blade diameter 800 mm
Compressed air 6/7 bar
Machine weight 2900 kg
- Italy
- Second hand
