Year of manufacture 2013
Sanding width 1.350 mm
Workpiece thickness min 3 mm
Passage height max 160 mm
Protection against workpiece over-thickness
Sanding aggregates total 2
Cross-belts 1
Sanding rollers 1
Steel roller
Combination unit 1
Sanding pads total 1
Segmental pressure pad electronic
Segment width 25 mm
Jump-in control
Chevron belt unit longitudinal
BÜTFERING Sanding pad aggregate H Super Finish aggregate
Cleaning brush Yes
Lacquer sanding
Vacuum table
Vacuum fan
Constant passline height
Sensing of workpiece thickness Wireless measuring clamp
BÜTFERING ME 5000 Wireless workpiece thickness measuring device
Main motor power 22 kW
Sanding belt length 2.150 mm
Adjustable sanding belt speed continuously variable
Feed min 2,5 m/min
Feedrate max 13 m/min
Continuously variable feed
Blow-off device Sanding belt
Ionisiereinrichtung Yes
Configuration of aggregates s-c-u
Side of belt change Left
BÜTFERING Automatic aggregate locking
BÜTFERING ARE Extensible workpiece support
BÜTFERING ATA 2 Supporting table, foldable
HOMAG ecoPlus
Control BÜTFERING TE 14
Declaration of CE-conformity
Conformity marking CE mark
Total connection 47 kW
Weight 4.400 kg
Space requirement Length 2,3 m
Space requirement Width 4,45 m
Space requirement Height 2,5 m
1st unit cross belt 13.5 kW | continuously adjustable 2 - 16 m/s
2nd unit combination 22 kW | continuously adjustable 2 - 18 m/s
https://www.hoechsmann.com/88298
2025-10-14 19:06:18
- Germany
- Second hand
