Year of manufacture 2019
Working dimension X 5.055 mm
Working dimension Y 1.650 mm
Working dimension Z 290 mm
Independent Z-axes 3
Number of milling spindles 1
Blow-off device
Milling spindle liquid-cooled
Main motor power 13 kW
Rotation speed max 24.000 rpm
Torque support
4th axis Yes
5th axis 5-axes spindle
Tool clamping system HSK-F63
Tool changer positions 28
Disc tool changer
Disc tool changer 16-fold
Number of exchangeable units 1
Vertical drilling spindles 20
Horizontal drilling spindles in X 4
Horizontal drilling spindles in Y 4
Groove saw in X-direction, in Y-direction
BIESSE Drilling aggregate BH 30 2L
Edgebanding aggregate Seperate Y-axis, PUR glue
BIESSE S.P.A. Edgebanding aggregate GU 60C
Spraying device Cleaning agent
BIESSE Multifunction units
Edgeband height max 65 mm
Gantry machine beidseitig angetriebene Gantrymaschine
Machine table Pod and rail table
Workpiece support aids with rollers
Two rows of stops
Electronic supervision of the end-position of the stops
Anzahl Vakuumzonen 24
Number of consoles 8
Positioning aid
BIESSE SA machine table
Vacuum pump
Number of vacuum pumps 1
Capacity vacuum pump 250 m³/h
Safety device Light barrier, Bumper
Chip conveyor
Interface for .dxf data
BIESSE bPad
Tool charge measurement
Automatic lubrication
Control BIESSE BH 660
Control cabinet cooling
Software BIESSE B_EDGE, BIESSE B_SOLID
Conformity marking CE mark
Total connection 31,13 kW
https://www.hoechsmann.com/59642
2025-09-29 15:34:37
- Germany
- Second hand
