Year of manufacture 2008
Working dimension X 3.000 mm
Working dimension Y 1.300 mm
Working dimension Z 90 mm
Independent Z-axes 2
Number of milling spindles 2
Main motor power 4,5 kW
Rotation speed max 24.000 rpm
Tool clamping system ISO 30
Vertical drilling spindles 62
Horizontal drilling spindles in X 16
Horizontal drilling spindles in Y 5
Six-sided workpiece processing
Groove saw in X-direction
Cantilever machine
Machine table Feed-through technology
Special workpiece clamping system clamp gripper
Feeding controlled pusher, Transversal buffer
Outfeed belt conveyor
Safety device Safety mat, enclosed fence
Interface for .dxf data
Control BIESSE XP 600
Software BIESSE BIESSEWORKS
Conformity marking CE mark
Weight 3.050 kg
Space requirement Length 8 m
Space requirement Width 4,8 m
Space requirement Height 2,5 m
