Year of manufacture 2017
Working dimension X 3.110 mm
Working dimension Y 1.320 mm
Working dimension Z 180 mm
Number of milling spindles 1
MORBIDELLI JQX spindle
Milling spindle liquid-cooled
Main motor power 10 kW
Rotation speed max 24.000 rpm
4th axis Yes
5th axis 5-axes spindle
Tool clamping system HSK-F63
Tool changer positions 25
SCM Tool changer FAST 14
SCM Tool changer TRB 11
Tool charge measurement
Vertical drilling spindles 18
SCM Drilling aggregate F 29 LTC
Horizontal drilling spindles in X 8
Horizontal drilling spindles in Y 4
Groove saw in X-direction
Cantilever machine
Machine table Pod and rail table
SCM Machine table TV FLEX
Workpiece support aids
Two rows of stops
Number of consoles 6
Positioning aid
Laser setup aid
Vacuum pump
Number of vacuum pumps 1
Capacity vacuum pump 250 m³/h
Safety device Bumper
SCM Pro-Space
Chip conveyor
Interface for .dxf data
Control PC control
MORBIDELLI TecPad
Software SCM XILOG MAESTRO, PC office licence
Declaration of CE-conformity
Conformity marking CE mark
Weight 4.475 kg
Space requirement Length 7,15 m
Space requirement Width 4,2 m
Space requirement Height 2,65 m
