Year of manufacture 2022
Working dimension X 3.100 mm
Working dimension Y 2.205 mm
Working dimension Z 250 mm
Number of milling spindles 1
BIESSE
Minimum lubrication
Milling spindle liquid-cooled
Main motor power 13 kW
Rotation speed max 24.000 rpm
Torque support
4th axis Yes
5th axis 5-axes spindle
Tool clamping system HSK-F63
Tool changer positions 24
Disc tool changer 8-fold
Pickup tool changer
Gantry machine beidseitig angetriebene Gantrymaschine
Machine table Matrix table
BIESSE Machine table FT PLUS
Three stop ranges
Electronic supervision of the end-position of the stops
Multi-zone vacuum
Anzahl Vakuumzonen 10
Vacuum pump
Number of vacuum pumps 2
Capacity vacuum pump 500 m³/h
Safety device Bumper
BIESSE Safety device FULL BUMPER
Interface for .dxf data
Tool charge measurement
Automatic lubrication
BIESSE Remote control unit RM 850
Control BIESSE BH 660
UPS - Uninterruptible Power Supply
Control cabinet cooling
Software BIESSE SOPHIA, BIESSE B_SOLID
Conformity marking CE mark, EAC mark
Unless expressly stated, tools, tool holders, aggregates, and mechanical clamps, which may be shown in photos and videos, are not part of the scope of delivery.
