Year of manufacture 2021
Edgeband thickness max 6 mm
Panel thickness max 60 mm
Thickness of coiled edgeband max 3 mm
Workpiece width min 95 mm
Feed min 12 m/min
Feedrate max 18 m/min
Continuously variable feed
Electromotoric height adjustment
Glue system granulate Premelting unit
SCM Glue system QMS-P Premelter
Magazine for single strips
Spraying device
Premilling unit
Trimming saw 2 motors
Flush/radius/chamfer milling units 1
Corner rounding unit 2 motors
SCM Corner rounding unit ROUND X
Scraper unit Profile scraper, Flat scraper
Buffing unit
Aggregates actuated by control NC-axes
Type left-side machine
Machine length 4.764 mm
Control SCM eye-M
Conformity marking CE mark
Weight 1.835 kg
Please note that the information on maximum edge thickness, panel thickness and feed speed is aggregate-dependent and may vary depending on the specific processing situation.
Technical data are partly taken from the manufacturer's brochure. Actual values may differ.
