Year of manufacture 2018
Edgeband thickness max 8 mm
Panel thickness max 60 mm
Thickness of coiled edgeband max 3 mm
Workpiece width min 70 mm
Feed min 8 m/min
Feedrate max 14 m/min
Continuously variable feed
Electromotoric height adjustment
Glue system granulate glue pot above feeding chain
HOMAG Glue system QA 65 N
Quick-change glue pot
Suitable for PUR glue
Magazine for single strips
Spraying device
Spraying device Release agent
Spraying device Lubricant
Premilling unit
Preheating zone
Andruckzone NC-gesteuert
Trimming saw 2 motors
Flush/radius/chamfer milling units 1
Corner rounding unit 2 motors
Scraper unit Profile scraper, Flat scraper
Buffing unit
Suitable for nesting Bündig/Radius/Fasestationen, Profile scraper
Aggregates actuated by control NC-axes
Type Right-side machine
Air cushion table on edgebanders
HOMAG Mechanical inflow lock
PU rollers
Control Homag powerTouch
Conformity marking CE mark
* Extraction manifold not included in the scope of delivery.
Please note that the information on maximum edge thickness, panel thickness and feed speed is aggregate-dependent and may vary depending on the specific processing situation.
Technical data are partly taken from the manufacturer's brochure. Actual values may differ.
