Year of manufacture 2020
Working dimension X 3.200 mm
Working dimension Y 900 mm
Working dimension Z 60 mm
Number of milling spindles 1
Main motor power 6,5 kW
Rotation speed max 24.000 rpm
Torque support
Tool clamping system ISO 30
Tool changer positions 8
Vertical drilling spindles 10
Horizontal drilling spindles in X 4
Horizontal drilling spindles in Y 2
Groove saw in X-direction
Vertical working surface
Machine table Feed-through technology
Special workpiece clamping system clamp gripper
Barcode reader
Safety device Safety mat
Interface for .dxf data
Control PC control
Software BIESSE SOPHIA, BIESSE B_SOLID
Declaration of CE-conformity
Conformity marking EAC mark, CE mark
Total connection 12 kW
Space requirement Length 5 m
Space requirement Width 1,94 m
Space requirement Height 2 m
Unless expressly stated, tools, tool holders, aggregates, and mechanical clamps, which may be shown in photos and videos, are not part of the scope of delivery.
