Year of manufacture 2010
Working dimension X 4.469 mm
Working dimension Y 1.600 mm
Working dimension Z 180 mm
Number of milling spindles 1
Main motor power 11 kW
Rotation speed max 20.000 rpm
4th axis Yes
5th axis 5-axes spindle
Milling spindle liquid-cooled
Tool clamping system HSK-F63
Tool changer positions 22
Vertical drilling spindles 18
Horizontal drilling spindles in X 4
Horizontal drilling spindles in Y 4
Groove saw in X-direction
Gantry machine einseitig angetrieben
Machine table Pod and rail table
Workpiece support aids
Three stop ranges
Number of consoles 8
Positioning aid
Vacuum pump
Number of vacuum pumps 1
Capacity vacuum pump 100 m³/h
Safety device Bumper
Chip conveyor
Interface for .dxf data
Control PC control
Software SCM XILOG PLUS
Conformity marking CE mark
Weight 3.500 kg
Unless expressly stated, tools, tool holders, aggregates, and mechanical clamps, which may be shown in photos and videos, are not part of the scope of delivery.
