Year of manufacture 2017
Working dimension X 3.050 mm
Working dimension Y 1.250 mm
Working dimension Z 80 mm
Number of milling spindles 1
Main motor power 10 kW
Rotation speed max 24.000 rpm
Tool clamping system HSK-F63
Tool changer positions 4
Vertical drilling spindles 15
Horizontal drilling spindles in X 6
Horizontal drilling spindles in Y 4
Groove saw 90° turnable
Vertical working surface
Machine table Feed-through technology
Special workpiece clamping system clamp gripper
Outfeed Workpiece return
Barcode reader
Dowel insertion
Glue system PVAc
Dowel diameter 8 mm
Dowel length max 35 mm
Safety device enclosed cabin
Milling for fittings Yes
HOMAG Plausibility check
Control cabinet cooling
Control HOMAG POWER CONTROL, Homag powerTouch
Software HOMAG WOODWOP, woodScan
Unless expressly stated, tools, tool holders, aggregates, and mechanical clamps, which may be shown in photos and videos, are not part of the scope of delivery.
Technical data are partly taken from the manufacturer's brochure. Actual values may differ.
