Year of manufacture 2011
Edgeband thickness max 8 mm
Panel thickness max 60 mm
Thickness of coiled edgeband max 3 mm
Workpiece length min 190 mm
Workpiece width min 80 mm
Feedrate max 10 m/min
Glue system granulate glue pot above feeding chain
Premilling unit
Trimming saw 1 motor
Flush/radius/chamfer milling units 1
Corner rounding unit 1 motor
Scraper unit Profile scraper, Flat scraper
Buffing unit
Aggregates actuated by control pneumatic
Type Right-side machine
Machine length 5.000 mm
Control Touchscreen, SPS
Conformity marking CE mark
Total connection 12,4 kW
Please note that the information on maximum edge thickness, panel thickness and feed speed is aggregate-dependent and may vary depending on the specific processing situation.
Technical data are partly taken from the manufacturer's brochure. Actual values may differ.
