Year of manufacture 2017
Working dimension X 8.500 mm
Working dimension Y 2.600 mm
Working dimension Z 200 mm
Independent Z-axes 3
Number of milling spindles 2
Milling spindle liquid-cooled
Main motor power 20 kW
Rotation speed max 24.000 rpm
Torque support
4th axis Yes
5th axis 5-axes spindle
Tool clamping system HSK-F63
Tool changer positions 37
Disc tool changer 24-fold
Disc tool changer
Pickup change place
Vertical drilling spindles 8
Groove saw in Y-direction
Gantry machine beidseitig angetriebene Gantrymaschine
Machine table Pod and rail table, Pin system, Feed-through technology
Number of consoles 10
Self-adjusting machine table
Vacuum pump
Pressure vessel
Number of vacuum pumps 1
Capacity vacuum pump 250 m³/h
Safety device Bumper, Light barrier
Chip conveyor
Control SIEMENS SINUMERIK 840 D SL
UPS - Uninterruptible Power Supply
Weight 20.000 kg
Space requirement Length 14 m
Space requirement Width 6,8 m
Space requirement Height 3,9 m
Unless expressly stated, tools, tool holders, aggregates, and mechanical clamps, which may be shown in photos and videos, are not part of the scope of delivery.
https://www.hoechsmann.com/82575
2025-07-25 09:57:34
- Germany
- Second hand
