Year of manufacture 2016
Working dimension X 4.825 mm
Working dimension Y 1.930 mm
Working dimension Z 425 mm
Independent Z-axes 2
Number of milling spindles 1
Milling spindle liquid-cooled
Main motor power 16,5 kW
Rotation speed max 24.000 rpm
Torque support
4th axis Yes
5th axis 5-axes spindle
Tool clamping system HSK-F63
Tool changer positions 22
Chain changer 22 positions
Vertical drilling spindles 16
BIESSE Drilling aggregate BH 29 L
Horizontal drilling spindles in X 8
Horizontal drilling spindles in Y 4
Groove saw in X-direction
Gantry machine Yes
Machine table Pod and rail table
Number of consoles 10
Self-adjusting machine table
BIESSE Automatic machine table EPS
Vacuum pump
Number of vacuum pumps 1
Capacity vacuum pump 250 m³/h
Safety device Safety mat
Chip conveyor
Two rows of stops
Workpiece support aids
Handheld terminal
Automatic central lubrication
Pendulum machining
Control cabinet cooling
UPS - Uninterruptible Power Supply
Control PC control
Conformity marking CE mark
Total connection 20 kW
Weight 7.350 kg
Unless expressly stated, tools, tool holders, aggregates, and mechanical clamps, which may be shown in photos and videos, are not part of the scope of delivery.
