Year of manufacture 2011
Cutting length 4.300 mm
Width of lifting table 2.200 mm
Number of grippers 9
HOLZMA 2-fingered grippers
Feedrate max 150 m/min
Continuously variable feed
Panel thickness min 9,5 mm
Saw blade projection 95 mm
Saw blade diameter max 380 mm
Main motor power 18 kW
Scoring saw Motoric adjustment
Loading by vacuum lifter
Labelling automatic, manually
HOLZMA Label printer integrated in the pressure beam
HOLZMA PICA 108
Lift table loading from behind
HOLZMA Vacuum loading 2in1
Turning device in the Machine table
For sensible workpieces Clamping pressure adjustable
Stop side Right side
HOLZMA Central side aligner
Head aligner
HOLZMA Pressure beam height control
Control HOLZMA CADMATIC 4.0 PROFESSIONAL
Declaration of CE-conformity
Conformity marking CE mark
Total connection 32 kW
https://www.hoechsmann.com/80290
2025-08-15 11:19:14
- Germany
- Second hand
