Year of manufacture 2018
Sanding width 1.100 mm
Workpiece thickness min 3 mm
Passage height max 160 mm
Protection against workpiece over-thickness
Sanding aggregates total 3
Sanding rollers 2
Hardness grade of roller in ° shore 80
Sanding pads total 1
Segmental pressure pad electronic
Segment width 22 mm
Jump-in control electropneumatically
Jump-in control
Diagonal aggregate
Lacquer sanding
Vacuum table
Vacuum fan
Constant passline height
Main motor power 18,5 kW
Sanding belt length 2.000 mm
Adjustable sanding belt speed continuously variable
Aggregates with frequency inverters 2
Feed min 3 m/min
Feedrate max 15 m/min
Continuously variable feed
Blow-off device Sanding belt
Configuration of aggregates r-r-p
Side of belt change Left
Control KÜNDIG TOUCHSCREEN, OMRON NT
KÜNDIG Enormatic
Declaration of CE-conformity
Conformity marking CE mark
Total connection 49,07 kW
Weight 3.400 kg
Space requirement Length 2,4 m
Space requirement Width 1,7 m
Space requirement Height 2,1 m
* Motorleistung :
- 1. Walze 80 SH / 18,5KW
- 2. Walze 45 SH / 15 KW
- 3. Schuh 11 KW
