Year of manufacture 2018
Edgeband thickness max 12 mm
Panel thickness max 60 mm
Thickness of coiled edgeband max 3 mm
Workpiece width min 70 mm
Feed min 8 m/min
Feedrate max 18 m/min
PU rollers
Continuously variable feed
Electromotoric height adjustment
Glue system granulate glue pot above feeding chain
HOMAG GMBH Glue system QA 65 N
Quick-change glue pot
Suitable for PUR glue
PUR Aufschmelzeinheit externer PUR-Aufschmelzer
balti PUME-04
Magazine for single strips
Spraying device
Spraying device Release agent
Spraying device Lubricant
Spraying device Cleaning agent
Premilling unit
Preheating zone
Andruckzone NC-gesteuert
Trimming saw 2 motors
Flush/radius/chamfer milling units 1
HOMAG GMBH Fine milling unit MS 40 Multistage trimming unit
Corner rounding unit 2 motors
HOMAG GMBH Corner rounding unit MF 50
HOMAG GMBH flexTrim
Scraper unit Profile scraper, Flat scraper
HOMAG GMBH Scraper unit MZ 40 Multistage scraper unit
Buffing unit
Edge sanding
Edge sanding aggregate 1
Suitable for nesting Bündig/Radius/Fasestationen, Profile scraper
Aggregates actuated by control NC-axes
Profilwechsel automatisch Bündig/Radius/Fasestationen, Profile scraper, Eckenkopieraggregat
Type Right-side machine
Machine length 7.100 mm
Control Homag powerTouch
Conformity marking EAC mark, CE mark
Including the machine-specific suction pipe distributor.
https://www.hoechsmann.com/62469
2025-09-11 13:50:08
- Germany
- Second hand
