Year of manufacture 2016
Working dimension X 3.540 mm
Working dimension Y 1.287 mm
Working dimension Z 180 mm
Number of milling spindles 1
Main motor power 15 kW
Rotation speed max 24.000 rpm
Torque support
4th axis C-axis
Tool clamping system HSK-F63
Tool changer positions 18
Number of exchangeable units 1
Vertical drilling spindles 18
Horizontal drilling spindles in X 4
Horizontal drilling spindles in Y 2
Groove saw in X-direction
Cantilever machine
Machine table Pod and rail table
Workpiece support aids
Number of consoles 6
Positioning aid
Point-type laser
Vacuum pump
Number of vacuum pumps 1
Capacity vacuum pump 140 m³/h
Safety device Safety mat
Interface for .dxf data
Control BECKHOFF CONTROL
Software HOLZ-HER CAMPUS
Conformity marking CE mark
Unless expressly stated, tools, tool holders, aggregates, and mechanical clamps, which may be shown in photos and videos, are not part of the scope of delivery.
Technical data are partly taken from the manufacturer's brochure. Actual values may differ.
https://www.hoechsmann.com/67884
2025-06-05 13:27:24
- Germany
- Second hand
