Year of manufacture 2018
Working dimension Z 200 mm
Number of milling spindles 1
Milling spindle liquid-cooled
Main motor power 12 kW
Rotation speed max 24.000 rpm
4th axis Yes
5th axis 5-axes spindle
Tool clamping system HSK-F63
Tool changer positions 22
Disc tool changer 22-fold
Vertical drilling spindles 13
Horizontal drilling spindles in X 4
Horizontal drilling spindles in Y 2
Groove saw in X-direction
Cantilever machine
Machine table Pod and rail table
Two rows of stops
Workpiece support aids
Pendulum machining
Number of consoles 6
Vacuum pump
Number of vacuum pumps 1
Capacity vacuum pump 90 m³/h
Safety device Bumper
Interface for .dxf data
Automatic lubrication
Remote control
Control PC control
Control cabinet cooling
Software MASTERWOOD MASTER AT, MASTERWOOD MASTER 3D, MASTERWOOD MASTERWORK, MICROSOFT WINDOWS 7
Conformity marking CE mark
Total connection 27 kW
Weight 3.655 kg
Space requirement Length 7,5 m
Space requirement Width 4,7 m
Space requirement Height 3,05 m
https://www.hoechsmann.com/59106
2025-02-18 16:40:54
- Germany
- Second hand
