Year of manufacture 2018
Working dimension X 3.500 mm
Working dimension Y 950 mm
Working dimension Z 80 mm
Number of milling spindles 1
Main motor power 12 kW
Rotation speed max 24.000 rpm
Torque support
Tool clamping system HSK-F63
Tool changer positions 5
Linear tool changer
Tool changing auxiliary device
Vertical drilling spindles 11
FORMAT 4 Drilling aggregate DH 17 6H 1S
Horizontal drilling spindles in X 4
Horizontal drilling spindles in Y 2
Groove saw in X-direction
Lock recess milling aggregate Unit, changeable
Machine table Feed-through technology
Special workpiece clamping system clamp gripper
Barcode reader
Safety device enclosed cabin
Workpiece length measurement
Handheld terminal
Automatic central lubrication
Control PC control
Software FORMAT 4 WOOD FLASH, FORMAT 4 WOOD FLASH AV-LIZENZ, TPA ALBATROS 3
Declaration of CE-conformity
Conformity marking CE mark
Total connection 14 kW
Weight 2.000 kg
Space requirement Length 5,9 m
Space requirement Width 4,45 m
Space requirement Height 2,3 m
