Year of manufacture 2018
Working width 230 mm
Planing height 160 mm
Number of spindles 6
Bottom spindles 2
Right spindles 1
Spindles left 1
Spindles top 2
Spindle configuration b-r-l-t-t-b
Spindle rotation speed max 1/min 7.000 rpm
Spindle diameter 40 mm
Feedrate max 40 m/min
Continuously variable feed
Feed motor 7 kW
Main motor power 11 kW
Motoric adjustment Programmable controller
Infeed table length 2.000 mm
Lubrication pump manually
Pneumatic top pressure
First infeed roller controlled
Type of feed roller drive Cardanic
Control WEINIG MEMORY PLUS-SYSTEM
Conformity marking CE mark
Weight 3.100 kg
Spindle power:
-bottom: 5,5 KW
-right/left: 11 KW motor
-top: 7.5 KW
-top: 7.5 KW
-bottom: 7.5 KW
https://www.hoechsmann.com/59689
2025-02-19 15:24:22
- Germany
- Second hand
