Year of manufacture 2018
Working width 230 mm
Planing height 160 mm
Number of spindles 5
Bottom spindles 2
Right spindles 1
Spindles left 1
Spindles top 1
Spindle configuration b-r-l-t-b
Spindle rotation speed max 1/min 6.800 rpm
Spindle diameter 40 mm
Main motor power 7,5 kW
Chip rabbet cutter
Seperate motor per spindle
Motoric adjustment Planing height
Surface of the machine table Chromed
Infeed table length 2.000 mm
Table rollers driven
Lubrication pump manually
Pneumatic top pressure
Feedrate max 36 m/min
Continuously variable feed
Feed motor 4 kW
Type of feed roller drive Cardanic
Control SPS
Weight 4.600 kg
CE marking
Declaration of CE-conformity
Total connection 38,25 kW
Space required Length 4.200 mm
Space required Width 2.400 mm
Space required Height 2.200 mm
Spindle power:
-bottom 7.5 kW
-right 5.5 kW
-left 5.5 kW
-top 7.5 kW
-bottom 7.5 kW
https://www.hoechsmann.com/18175
2024-02-14 07:45:27
- Germany
- Second hand
