Year of manufacture 2021
Edgeband thickness max 3 mm
Panel thickness max 60 mm
Thickness of coiled edgeband max 3 mm
Workpiece length min 130 mm
Feed min 6 m/min
Feedrate max 30 m/min
Continuously variable feed
Electromotoric height adjustment
Top pressure by belt
Spraying device
Premilling unit
Glue system granulate glue pot above feeding chain
Suitable for PUR glue
PUR Melting unit Yes
Places in coil magazine 6
Trimming saw 2 motors
Flush/radius/chamfer milling units 2
Corner rounding unit 1 motor
Groove milling aggregate Universal milling aggregate tiltable
Scraper unit Profile scraper, Flat scraper
Buffing unit
Aggregates actuated by control NC-axes
Type left-side machine
Control IMA ICOS OPEN
Conformity marking CE mark
Please note that the information on maximum edge thickness, panel thickness and feed speed is aggregate-dependent and may vary depending on the specific processing situation.
Technical data are partly taken from the manufacturer's brochure. Actual values may differ.
Machine length estimated.
