Year of manufacture 2021
Edgeband thickness max 12 mm
Panel thickness max 60 mm
Thickness of coiled edgeband max 3 mm
Feedrate max 18 m/min
Electromotoric height adjustment
Spraying device
Spraying device Release agent
Spraying device Antistatic coolant spraying unit
Premilling unit
BIESSE Autoset
Zero joint Hot air
BIESSE AirForce-System
Glue system granulate Premelting unit
Suitable for PUR glue
Magazine for single strips
Andruckzone NC-gesteuert
Trimming saw 2 motors
BIESSE Trimming saw IN 801
Flush/radius/chamfer milling units 1
Corner rounding unit 2 motors
BIESSE Corner rounding unit AR 02 E
Finishing aggregate Hot air
Aggregates actuated by control NC-axes
Profilwechsel automatisch Bündig/Radius/Fasestationen, Profile scraper
Type left-side machine
Machine length 5.610 mm
Automatic lubrication
Air cushion table on edgebanders
Conformity marking CE mark, EAC mark
Total connection 21 kW
Space requirement Length 5,61 m
Space requirement Width 1,62 m
Space requirement Height 1,72 m
Please note that the information on maximum edge thickness, panel thickness and feed speed is aggregate-dependent and may vary depending on the specific processing situation.
