Year of manufacture 2022
Edgeband thickness max 12 mm
Panel thickness max 60 mm
Thickness of coiled edgeband max 3 mm
Workpiece length min 240 mm
Workpiece width min 60 mm
Feed min 16 m/min
Feedrate max 20 m/min
Continuously variable feed
Electromotoric height adjustment
Top pressure by belt
Spraying device
Premilling unit
Preheating zone
Zero joint Hot air
HOMAG airTec
Glue system granulate Premelting unit
PUR Aufschmelzeinheit externer PUR-Aufschmelzer
HOMAG XES 200
Trimming saw 2 motors
Flush/radius/chamfer milling units 2
Corner rounding unit 2 motors
HOMAG Corner rounding unit MF 60 Multifunctional trimming unit with corner rounding
Scraper unit Profile scraper, Flat scraper
HOMAG Fine milling unit MS 40 Multistage trimming unit
Buffing unit
Aggregates actuated by control NC-axes
Type left-side machine
Machine length 9.365 mm
HOMAG Mechanical inflow lock
Control HOMAG POWER CONTROL PC 23, Homag powerTouch
Total connection 40,16 kW
Please note that the information on maximum edge thickness, panel thickness and feed speed is aggregate-dependent and may vary depending on the specific processing situation.
Technical data are partly taken from the manufacturer's brochure. Actual values may differ.
https://www.hoechsmann.com/101374
2026-06-15 10:42:59
- Germany
- Second hand
