Year of manufacture 2019
Edgeband thickness max 30 mm
Panel thickness max 37,2 mm
Thickness of coiled edgeband max 3 mm
Workpiece length min 150 mm
Workpiece width min 150 mm
Feed min 6 m/min
Feedrate max 30 m/min
Continuously variable feed
Electromotoric height adjustment
Top pressure by belt
Sizing unit Moulding aggregates
IMA Premilling unit 08.378
Premilling unit
IMA Premilling unit 08.378
Preheating zone
Glue system cartridge
IMA Glue system 283.203 PUR Quickmelt
Quick-change glue pot
Suitable for PUR glue
PUR Aufschmelzeinheit interner PUR-Aufschmelzer
Magazine for single strips
Trimming saw 2 motors
IMA Trimming saw 08.42
Flush/radius/chamfer milling units 2
IMA Fine milling unit 08.0587 Multiple profile milling aggregate
Edge sanding
Aggregates actuated by control NC-axes, pneumatic
Profilwechsel automatisch Bündig/Radius/Fasestationen
Type left-side machine
Machine length 15.170 mm
Control IMA ICOS OPEN
Conformity marking CE mark
Total connection 44 kW
Space requirement Length 22,96 m
Space requirement Height 2,6 m
Please note that the information on maximum edge thickness, panel thickness and feed speed is aggregate-dependent and may vary depending on the specific processing situation.
Machine with special equipment for veneered panels, edge banding on panels with an overhanging top layer. The edge banding material is glued underneath the veneer.
Includes air cushion tables at the infeed and outfeed
