Year of manufacture 2017
Edgeband thickness max 8 mm
Panel thickness max 60 mm
Thickness of coiled edgeband max 3 mm
Workpiece length min 150 mm
Workpiece width min 50 mm
Feedrate max 12 m/min
Spraying device
Premilling unit
Glue system granulate glue pot below feeding chain
Trimming saw 2 motors
Flush/radius/chamfer milling units 1
Corner rounding unit 2 motors
Scraper unit Profile scraper, Flat scraper
Buffing unit
Aggregates actuated by control pneumatic
Type left-side machine
Machine length 5.213 mm
Control BIESSE SMART TOUCH 7 "
Conformity marking CE mark
Total connection 10 kW
Weight 1.650 kg
Please note that the information on maximum edge thickness, panel thickness and feed speed is aggregate-dependent and may vary depending on the specific processing situation.
