Year of manufacture 2021
Sanding width 1.350 mm
Workpiece thickness min 3 mm
Passage height max 170 mm
Sanding aggregates total 2
Cross-belts 1
Cross belt speed adjustable continuously variable
Sanding pads total 1
Segmental pressure pad electronic
SCM Segmental pressure pad EPICS
Segment width 16 mm
Jump-in control electropneumatically
Jump-in control
Chevron belt unit longitudinal
Sanding brush unit Disc brush unit, Drum sanding brushes
Lacquer sanding
Vacuum table
Vacuum fan
Constant passline height
Main motor power 15 kW
Sanding belt length 2.620 mm
Adjustable sanding belt speed continuously variable
Aggregates with frequency inverters 2
Blow-off device Sanding belt
Configuration of aggregates q-b-b-b-s-b
Side of belt change Left
Control SCM eye-M
Software SCM Maestro pro sand
Conformity marking CE mark
Weight 6.250 kg
Technical data are partly taken from the manufacturer's brochure. Actual values may differ.
