Year of manufacture 2021
Edgeband thickness max 8 mm
Panel thickness max 60 mm
Thickness of coiled edgeband max 3 mm
Workpiece length min 160 mm
Workpiece width min 60 mm
Feedrate max 18 m/min
Continuously variable feed
Electromotoric height adjustment
Spraying device
Spraying device Release agent
Spraying device Antistatic coolant spraying unit
Spraying device Cleaning agent
Premilling unit
HOLZ-HER Premilling unit 1802
Glue system cartridge
HOLZ-HER Glue system GLU JET GJ301AUTOMATIK
Suitable for PUR glue
Magazine for single strips
Trimming saw 2 motors
HOLZ-HER Trimming saw 1918/60 PNEU
Flush/radius/chamfer milling units 1
HOLZ-HER Fine milling unit FR 701
Corner rounding unit 2 motors
HOLZ-HER Corner rounding unit FF 701
Scraper unit Profile scraper, Flat scraper
HOLZ-HER Profile scraper unit ZK 502 MOT6
HOLZ-HER Scraper unit FK 701
Buffing unit
HOLZ-HER Buffing unit 1940
Suitable for nesting Bündig/Radius/Fasestationen, Profile scraper
Aggregates actuated by control NC-axes
Type left-side machine
Machine length 5.740 mm
Control HOLZ-HER EDGECONTROL TOUCH PPC 319
Conformity marking CE mark
Please note that the information on maximum edge thickness, panel thickness and feed speed is aggregate-dependent and may vary depending on the specific processing situation.
