Year of manufacture 2014
Edgeband thickness max 8 mm
Panel thickness max 60 mm
Thickness of coiled edgeband max 3 mm
Workpiece length min 160 mm
Workpiece width min 60 mm
Feed min 10 m/min
Feedrate max 18 m/min
Continuously variable feed
Glue system cartridge
Glue system granulate direktes Aufschmelzsystem
HOLZ-HER Glue system GLU JET GJ 301
Suitable for PUR glue
Magazine for single strips
Spraying device
HOLZ-HER Spraying device 1856
Premilling unit
HOLZ-HER Premilling unit 1802
Trimming saw 2 motors
HOLZ-HER Trimming saw 1918
Flush/radius/chamfer milling units 1
HOLZ-HER Fine milling unit 1826
Corner rounding unit 2 motors
HOLZ-HER Corner rounding unit 1833
Scraper unit Profile scraper, Flat scraper
HOLZ-HER Profile scraper unit 1929
Buffing unit
Aggregates actuated by control NC-axes
Type left-side machine
Machine length 5.696 mm
Control HOLZ-HER EDGECONTROL PPC 231
Please note that the information on maximum edge thickness, panel thickness and feed speed is aggregate-dependent and may vary depending on the specific processing situation.
