Year of manufacture 2010
Edgeband thickness max 10 mm
Panel thickness max 60 mm
Thickness of coiled edgeband max 3 mm
Workpiece length min 140 mm
Workpiece width min 85 mm
Feedrate max 12 m/min
Electromotoric height adjustment
Glue system granulate glue pot below feeding chain
Quick-change glue pot
Magazine for single strips
Premilling unit
Trimming saw 2 motors
Flush/radius/chamfer milling units 1
Corner rounding unit 2 motors
Scraper unit Profile scraper, Flat scraper
Buffing unit
Aggregates actuated by control pneumatic
Type left-side machine
Machine length 5.144 mm
Control BIESSE ARTECH TS 10
Conformity marking CE mark
Total connection 13 kW
* Includes 2 glue basins, which would need to be refurbished.
Please note that the information on maximum edge thickness, panel thickness and feed speed is aggregate-dependent and may vary depending on the specific processing situation.
Technical data are partly taken from the manufacturer's brochure. Actual values may differ.
