Year of manufacture 2014
Working dimension X 4.375 mm
Working dimension Y 1.550 mm
Number of milling spindles 1
Main motor power 15 kW
Rotation speed max 24.000 rpm
Torque support
4th axis Yes
5th axis 5-axes spindle
Tool clamping system HSK-F63
Tool changer positions 14
Disc tool changer 14-fold
Vertical drilling spindles 12
Horizontal drilling spindles in X 2
Horizontal drilling spindles in Y 2
Groove saw 90° turnable
Gantry machine Yes
Machine table Pod and rail table
Number of consoles 8
Positioning aid
LED luminous tape
Vacuum pump
Number of vacuum pumps 2
Capacity vacuum pump 219 m³/h
Feeding vacuum lifter
Safety device Light barrier, Bumper
Control HOMAG POWER CONTROL PC 85
Declaration of CE-conformity
Conformity marking CE mark
Total connection 34 kW
Weight 10.455 kg
Space requirement Length 12,2 m
Space requirement Width 5,2 m
Space requirement Height 2,8 m
