Smart Touch Numerical Control with Sintra HD Software
Panel height mm 10 - 60
Solid 22 mm PVC/ABS mm 3
Feed speed up to 25 m/min
Working height adjustable electronically by C.N.
Motorized rubber belt with higher pressure
Panel support guide motorized and electronically adjustable by C.N. Air curtain table for panel introduction Side roller conveyor with idle wheels for panel support Anti-adhesive group
Rectifier unit with 2 electronically adjustable motors by C.N. AdIRL-700 Panel Edge Heating Lamps
Single position reel holder plate
Gluing unit for EVA hot melt glue with glue pot and pre-melter
Edge pressure group on straight profiles with pressure rollers electronically adjustable by C.N End trimming unit with 2 IT 70 P motors
Overlapping trimming group with 2 motors
Staggered edge trimming unit with 2 motors electronically adjustable by C.N.
Anti-stick group
Rounding unit with 2 multifunction motors (cornering tool + rounding tool)
Non-stick liquid application system
Electronic edge scraper group electronically adjustable by NC
Glue scraper group 0-90° tilting tupie group
Brush group 3800 kg
Total installed power KW 27
TECHNICAL DETAILS TO BE CHECKED
- Italy
- Second hand
