Year of manufacture 2017
Sanding width 1.100 mm
Workpiece thickness min 3 mm
Passage height max 170 mm
Sanding aggregates total 2
Sanding rollers 2
Combination unit 1
Sanding pads total 1
Segmental pressure pad electronic
Segment width 25 mm
Jump-in control electropneumatically
Jump-in control
Lacquer sanding
Vacuum table
Sensing of workpiece thickness mechanical
Main motor power 11 kW
Sanding belt length 2.200 mm
Adjustable sanding belt speed continuously variable
Aggregates with frequency inverters 1
Feed min 2,8 m/min
Feedrate max 20 m/min
Continuously variable feed
Blow-off device Sanding belt
Configuration of aggregates r-c
Side of belt change Left
Control Touchscreen
Conformity marking CE mark
Total connection 22 kW
Space requirement Length 2,3 m
Space requirement Width 1,7 m
Space requirement Height 2,2 m
Technical data are partly taken from the manufacturer's brochure. Actual values may differ.
