Year of manufacture 2018
Working dimension X 3.650 mm
Working dimension Y 2.120 mm
Working dimension Z 170 mm
Number of milling spindles 1
Milling spindle liquid-cooled
SCM 5-axes spindle PRISMA KS
Main motor power 12 kW
Rotation speed max 24.000 rpm
Torque support
4th axis Yes
5th axis 5-axes spindle
Tool clamping system HSK-F63
Tool changer positions 28
SCM Tool changer TR 12
SCM Tool changer RAPID 16
Vertical drilling spindles 12
Horizontal drilling spindles in X 4
Horizontal drilling spindles in Y 2
Groove saw in X-direction
SCM Drilling aggregate F 18 L
Gantry machine beidseitig angetriebene Gantrymaschine
Machine table Matrix table
Vacuum pump
Number of vacuum pumps 2
Capacity vacuum pump 500 m³/h
Workpiece probing
Werkstückdickenmessung
Suitable for nesting
Safety device Bumper, Light barrier
SCM Pro-Speed
Interface for .dxf data
Tool charge measurement
Automatic central lubrication
Remote control
Control PC control
Software SCM XILOG MAESTRO, MICROSOFT WINDOWS 7
Conformity marking CE mark
Weight 6.200 kg
Space requirement Length 7,15 m
Space requirement Width 6,4 m
Space requirement Height 2,9 m
Unless expressly stated, tools, tool holders, aggregates, and mechanical clamps, which may be shown in photos and videos, are not part of the scope of delivery.
Technical data are partly taken from the manufacturer's brochure. Actual values may differ.
