Year of manufacture 2019
Edgeband thickness max 3 mm
Panel thickness max 60 mm
Thickness of coiled edgeband max 3 mm
Workpiece length min 200 mm
Workpiece width min 80 mm
Feedrate max 10 m/min
Glue system granulate glue pot above feeding chain
Quick-change glue pot
Premilling unit
Trimming saw 1 motor
Flush/radius/chamfer milling units 2
Corner rounding unit 1 motor
Scraper unit Profile scraper, Flat scraper
Buffing unit
Aggregates actuated by control pneumatic
Type right-side machine
Machine length 5.250 mm
Control Touchscreen
Conformity marking CE mark
Please note that the information on maximum edge thickness, panel thickness and feed speed is aggregate-dependent and may vary depending on the specific processing situation.
Currently, jointing cutters with a height of 48 mm are installed. Other jointing cutters are required to process 60 mm panels!
https://www.hoechsmann.com/68016
2025-05-20 11:21:13
- Germany
- Second hand
