Year of manufacture 2020
Sanding width 1.350 mm
Workpiece thickness min 3 mm
Passage height max 170 mm
Sanding aggregates total 3
Cross-belts 1
SCM Segmental pressure pad EPICS
Cross belt speed adjustable continuously variable
Sanding rollers 1
Steel roller
Sanding pads total 1
Segmental pressure pad electronic
SCM Segmental pressure pad EPICS
Segment width 32 mm
Jump-in control electropneumatically
Jump-in control
Chevron belt unit longitudinal
Sanding brush unit Drum sanding brushes
Lacquer sanding
Vacuum table
Vacuum fan
Main motor power 15 kW
Sanding belt length 2.620 mm
Aggregates with frequency inverters 3
Continuously variable feed
Blow-off device Workpieces, Sanding belt
Configuration of aggregates s-r-p-u
Side of belt change Left
SCM Segmental pressure pad EPICS
Control Touchscreen
Software SCM MAESTRO CONNECT, SCM MAESTRO ACTIVE SAND
Declaration of CE-conformity
Conformity marking CE mark
Space requirement Length 2,4 m
Space requirement Width 2,05 m
Space requirement Height 2,425 m
Configuration:
* BL 32 workpiece scanning with 32 mm grid
* TA 5000 cross sanding unit with electronic EPICS segment pad, 15 kW, variable belt speed
* R 250 sanding roller unit with steel roller, 15 kW
* S-2620 superfinishing sanding pad unit with chevron belt and EPICS segment pad, 11 kW, variable belt speed
* SB 200 UFC finish sanding brush unit with silicon carbide fibers
* Antistatic bar
https://www.hoechsmann.com/19009
2025-10-13 13:14:58
- Germany
- Second hand
