Year of manufacture 2018
Workpiece return Conveyor belt, Air cushion table
Edgeband thickness max 3 mm
Panel thickness max 60 mm
Thickness of coiled edgeband max 3 mm
Workpiece length min 150 mm
Workpiece width min 100 mm
Feed min 10 m/min
Feedrate max 25 m/min
Continuously variable feed
Electromotoric height adjustment
Top pressure by belt
Places in coil magazine 6
Zero joint Hot air
BIESSE AirForce-System
Suitable for PUR glue
PUR Aufschmelzeinheit externer PUR-Aufschmelzer
Spraying device
Spraying device Release agent
Spraying device Cleaning agent
Premilling unit
Preheating zone
Andruckzone NC-gesteuert
Trimming saw 2 motors
BIESSE Trimming saw IT 90-P
Flush/radius/chamfer milling units 1
BIESSE Fine milling unit RF 40
Corner rounding unit 2 motors
BIESSE Corner rounding unit AR 80 Multifunctional contour milling aggregate
Tool changer positions 8
Groove milling aggregate Universalfräsaggregat schwenkbar, Two aggregates
Scraper unit Profile scraper, Flat scraper
BIESSE Profile scraper unit RB 40
BIESSE Flat scraper unit RC 40
Buffing unit
BIESSE Buffing unit SZ 30
Finishing aggregate Hot air
BIESSE Smoothing station PH 10
Aggregates actuated by control NC-axes
Profilwechsel automatisch Bündig/Radius/Fasestationen, Eckenkopieraggregat, Profile scraper
Type left-side machine
Machine length 11.640 mm
Barcode reader
Air cushion table on edgebanders
Automatic lubrication
Control BIESSE SMART TOUCH, CNI SINTRA
Software MICROSOFT WINDOWS 7
Conformity marking CE mark, EAC mark
Total connection 35 kW
Weight 8.490 kg
Space requirement Length 15,5 m
Space requirement Width 4,7 m
Space requirement Height 1,5 m
Technical data are partly taken from the manufacturer's brochure. Actual values may differ.
