Year of manufacture 2010
Edgeband thickness max 6 mm
Panel thickness max 60 mm
Thickness of coiled edgeband max 3 mm
Workpiece length min 160 mm
Workpiece width min 65 mm
Feedrate max 10 m/min
Glue system cartridge
HOLZ-HER Glue system 1906MG
Suitable for PUR glue
Magazine for single strips
HOLZ-HER Edge magazine 1903
Premilling unit
HOLZ-HER Premilling unit 1801
Trimming saw 2 motors
HOLZ-HER Trimming saw 1918 PNEU
Flush/radius/chamfer milling units 1
HOLZ-HER Fine milling unit 1827 MOT4
Corner rounding unit 1 motor
HOLZ-HER Corner rounding unit 1832
Scraper unit Profile scraper, Flat scraper
HOLZ-HER Profile scraper unit 1929 MOT2
HOLZ-HER Flat scraper unit 1964
Aggregates actuated by control NC-axes, pneumatic
Type left-side machine
Machine length 4.630 mm
Control HOLZ-HER EDGECONTROL PPC 221
Conformity marking CE mark
Please note that the information on maximum edge thickness, panel thickness and feed speed is aggregate-dependent and may vary depending on the specific processing situation.
https://www.hoechsmann.com/99128
