Year of manufacture 2018
Sanding width 1.350 mm
Workpiece thickness min 3 mm
Passage height max 170 mm
Sanding aggregates total 3
Cross-belts 1
Cross belt speed adjustable continuously variable
Sanding rollers 1
Hardness grade of roller in ° shore 30 Shore
Sanding pads total 1
Segmental pressure pad electronic
Segment width 32 mm
Jump-in control electropneumatically
Jump-in control
Chevron belt unit longitudinal
Structuring unit Stahldrahtbürste
Cleaning brush Yes
Lacquer sanding
Vacuum table
Constant passline height
Main motor power 15 kW
Sanding belt length 2.620 mm
Adjustable sanding belt speed continuously variable
Aggregates with frequency inverters 3
Feed min 3 m/min
Feedrate max 18 m/min
Continuously variable feed
Blow-off device Workpieces, Sanding belt
SCM Oscillating nozzles
Rotating nozzles
Configuration of aggregates s-r-p-u
Side of belt change Left
Control B&R Power Panel
Conformity marking CE mark
