Year of manufacture 2021
Working dimension X 3.086 mm
Working dimension Y 2.155 mm
Working dimension Z 100 mm
Number of milling spindles 1
Main motor power 9,5 kW
Rotation speed max 24.000 rpm
Torque support
Tool clamping system HSK-F63
Tool changer positions 13
Linear tool changer
Vertical drilling spindles 12
Gantry machine beidseitig angetriebene Gantrymaschine
Machine table Matrix table
Vacuum pump
Number of vacuum pumps 2
Capacity vacuum pump 500 m³/h
Feeding Lift table
Outfeed Conveyor belt
Safety device Bumper
Interface for .dxf data
Control PC control
Software BUSELLATO WAVE
SCM XILOG PLUS
Conformity marking CE mark
Weight 6.563 kg
Space requirement Length 12,7 m
Space requirement Width 5,3 m
Space requirement Height 2,4 m
Unless expressly stated, tools, tool holders, aggregates, and mechanical clamps, which may be shown in photos and videos, are not part of the scope of delivery.
