Electronic control with PC Office
Software Xilog Plus
Remote control device to manage the main functions of the machine
Useful working sizes: 3.600 x 1.300 x 180 mm
Nr. 6 Bars TV (nr. 14 suctions)
Nr. 6 Front row stop
Nr. 6 Rear row stop
Nr. 6 Middle row stop
Nr. 6 Lifiting bars to lift the panel
Nr. 1 Electro spindle “5” axis (Prisma K) - 11 KW – HSK 63 – Tool changer RAPID at nr. 12 positions
Nr. 2 Lateral tool changer, one on the right with nr. 10 positions and one on the left with nr. 10 positions
Boring unit:
- Nr. 12 Independent vertical spindles
- Nr. 3 Independent horizontal spindles with double outlet, nr. 2 in “X” direction and nr. 1 in “Y” direction
- Saw blade fixed in “X” direction.
Nr. 1 Vaccum pump 100 m3/h
Automatic lubrication
Aspiration system optimized and centralyzed
Safety nets
CE Marks
