Year of manufacture 2018
Working dimension X 3.110 mm
Working dimension Y 1.620 mm
Working dimension Z 180 mm
Number of milling spindles 1
Milling spindle liquid-cooled
Main motor power 10 kW
Rotation speed max 24.000 rpm
4th axis Yes
5th axis 5-axes spindle
Tool clamping system HSK-F63
Tool changer positions 28
Linear tool changer
Pickup tool changer
Vertical drilling spindles 13
Horizontal drilling spindles in X 6
Horizontal drilling spindles in Y 4
Groove saw in X-direction
Cantilever machine
Machine table Pod and rail table
Number of consoles 6
Pneumatic pipe connectors an den Konsolen
Positioning aid
Crosshair laser
Vacuum pump
Number of vacuum pumps 1
Capacity vacuum pump 90 m³/h
Safety device Bumper
SCM Pro-Space
Chip conveyor
Workpiece support aids
Automatic central lubrication
Tool charge measurement
Control PC control
Software SCM XILOG PLUS, SCM XILOG MAESTRO
Declaration of CE-conformity
Conformity marking CE mark
Unless expressly stated, tools, tool holders, aggregates, and mechanical clamps, which may be shown in photos and videos, are not part of the scope of delivery.
