Year of manufacture 2009
Edgeband thickness max 20 mm
Panel thickness max 60 mm
Thickness of coiled edgeband max 3 mm
Workpiece length min 150 mm
Workpiece width min 55 mm
Feed min 18 m/min
Feedrate max 25 m/min
Continuously variable feed
Electromotoric height adjustment
Top pressure by belt
Places in coil magazine 2
Glue system cartridge
Quick-change glue pot
Suitable for PUR glue
PUR Aufschmelzeinheit interner PUR-Aufschmelzer
HOMAG Glue system PU 34
Magazine for single strips
Spraying device
Premilling unit
HOMAG Premilling unit S 2
Andruckzone NC-gesteuert
Trimming saw 2 motors
HOMAG Trimming saw HL 84
Flush/radius/chamfer milling units 1
Corner rounding unit 2 motors
HOMAG Corner rounding unit FK 13
Tool changer positions 8
Nutfräsaggregat Universalfräsaggregat schwenkbar
HOMAG Universal milling aggregate UF 11
Scraper unit Profile scraper, Flat scraper
HOMAG Scraper unit MN 21 AUTOMATISCH Multi-cleaning
HOMAG Flat scraper unit FA 11 Polishing aggregate
Buffing unit
Aggregates actuated by control pneumatic
Type left-side machine
Machine length 9.750 mm
Infeed barrier
Scissor support
Control powerControl PC 22
Software woodCommander
Conformity marking CE mark
Please note that the information on maximum edge thickness, panel thickness and feed speed is aggregate-dependent and may vary depending on the specific processing situation.
