Year of manufacture 2020
Sanding width 1.350 mm
Workpiece thickness min 3,5 mm
Passage height max 200 mm
Protection against workpiece over-thickness
Sanding aggregates total 4
Cross-belts 1
Cross belt speed adjustable continuously variable
Sanding rollers 1
Hardness grade of roller in ° shore 85
Sanding pads total 2
Segmental pressure pad electronic
Segment width 22 mm
Jump-in control electropneumatically
Jump-in control
Diagonal aggregate
Lacquer sanding
Vacuum table
Vacuum fan
Constant passline height
Sensing of workpiece thickness mechanical
Main motor power 18,5 kW
Sanding belt length 2.620 mm
Belt speed max 19 m/s
Adjustable sanding belt speed continuously variable
Aggregates with frequency inverters 3
Feed min 2 m/min
Feedrate max 15 m/min
Continuously variable feed
Blow-off device Workpieces, Sanding belt
Ionisiereinrichtung Yes
Configuration of aggregates w-s-s-q
Side of belt change Left
Control KÜNDIG TOUCHSCREEN
KÜNDIG Enormatic
Declaration of CE-conformity
Conformity marking CE mark
Total connection 72 kW
Space requirement Length 4,8 m
Space requirement Width 3,4 m
Space requirement Height 2,6 m
