Year of manufacture 2018
Working dimension X 3.500 mm
Working dimension Y 950 mm
Working dimension Z 80 mm
Number of milling spindles 1
Main motor power 12 kW
Rotation speed max 24.000 rpm
Tool clamping system HSK-F63
Tool changer positions 4
Vertical drilling spindles 11
Horizontal drilling spindles in X 4
Horizontal drilling spindles in Y 2
Groove saw in X-direction
Machine table Feed-through technology
Special workpiece clamping system clamp gripper
Dowel insertion
Safety device enclosed cabin
Interface for .dxf data
Control PC control
Software FORMAT 4 WOOD FLASH, FORMAT 4 WOOD FLASH AV-LIZENZ
Conformity marking CE mark
Total connection 14 kW
Space requirement Length 2,4 m
Space requirement Width 2,1 m
Space requirement Height 2,3 m
Unless expressly stated, tools, tool holders, aggregates, and mechanical clamps, which may be shown in photos and videos, are not part of the scope of delivery.
