Year of manufacture 2016
Edgeband thickness max 12 mm
Panel thickness max 60 mm
Thickness of coiled edgeband max 3 mm
Feedrate max 20 m/min
Electromotoric height adjustment
Glue system granulate glue pot below feeding chain
Quick-change glue pot
Suitable for PUR glue
Magazine for single strips
Spraying device
Premilling unit
Preheating zone
Andruckzone NC-gesteuert
Trimming saw 2 motors
Flush/radius/chamfer milling units 1
Corner rounding unit 2 motors
Scraper unit Profile scraper, Flat scraper
Buffing unit
Suitable for nesting Bündig/Radius/Fasestationen, Flat scraper
Aggregates actuated by control NC-axes
Type Right-side machine
Machine length 5.300 mm
Declaration of CE-conformity
Conformity marking CE mark
Total connection 11 kW
Weight 2.400 kg
Space requirement Length 5,3 m
Space requirement Width 1,8 m
Space requirement Height 1,7 m
Including vacuum container and service station
Please note that the information on maximum edge thickness, panel thickness and feed speed is aggregate-dependent and may vary depending on the specific processing situation.
