Year of manufacture 2012
Sanding width 1.100 mm
Workpiece thickness min 3 mm
Passage height max 150 mm
Sanding aggregates total 1
Sanding rollers 1
Steel roller
Combination unit 1
Sanding pads total 1
Segmental pressure pad electronic
Segment width 35 mm
Jump-in control electropneumatically
Jump-in control
Cleaning brush Yes
Vacuum table
Constant passline height
Sensing of workpiece thickness mechanical
Main motor power 15 kW
Sanding belt length 1.900 mm
Belt speed max 18 m/s
Adjustable sanding belt speed continuously variable
Aggregates with frequency inverters 1
Feed min 2,5 m/min
Feedrate max 13 m/min
Continuously variable feed
Blow-off device Sanding belt
Ionisiereinrichtung No
Configuration of aggregates c-u
Side of belt change Left
Control BÜTFERING TE 11
Declaration of CE-conformity
Conformity marking CE mark
Total connection 19 kW
Weight 1.900 kg
Space requirement Length 1,4 m
Space requirement Width 3,2 m
Space requirement Height 2,1 m
* without vacuum fan
